JNICON PRODUCT CATALOGUE

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA M19 SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon M19 Series QUICK-LOCK ASSEMBLY TYPE / SCREW LOCKING TYPE / MOLDED CABLE TYPE / PANEL MOUNT TYPE M19 push-locking assembly type - specifications below TECHNICAL SPECIFICATIONS Number of contacts 2 Pin 3 Pin 4 Pin 5/6/7/8 Pin 12 Pin Current / Voltage rating 20A 600V 20A 600V 15A 300V 15A+5A 300V+60V 5A 30V Contact diameter 2.4 2.4 2.0 2.0 + 0.8 1.0 Withstanding voltage 2500V 2500V 1500V 1000V 500V Protection level IP67 IP67 IP67 IP67 IP67 Cable gauge 1.5-2.5 mm2 1.5-2.5 mm2 0.5-1.5 mm2 0.5-1.5 mm2 0.3-0.5 mm2 Diameter range 4.5 - 11 mm 4.5 - 11 mm 4.5 - 11 mm 4.5 - 11 mm 4.5 - 11 mm Operating temperature -40 C ~ +105 C Connecting mode Push locking Shell / insulating parts High-performance engineering plastics Contact material Copper alloy Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS Compact 19 mm body 2 to 12 pin configurations Push-locking, fast mating IP67 sealed UL94-V0 flame rating Signal and control cabling LED and lighting systems Sensors and instrumentation Outdoor equipment WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA M25 SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon M25 Series BAYONET ASSEMBLY TYPE / SCREW LOCKING TYPE / MOLDED CABLE TYPE / PANEL MOUNT TYPE M25 push-locking assembly type - specifications below TECHNICAL SPECIFICATIONS Number of contacts 2 / 3 / 4 Pin 5 / 6 Pin 7 / 8 Pin 9 - 16 Pin Current / Voltage rating 50A 500V 30A/20A 300V 15A/10A 300V 10A/5A 120V-30V Contact diameter 3.5 2.7 / 2.4 2.0 / 1.5 1.5 / 1.0 Withstanding voltage 2500V 2000V 1500V 1000V Protection level IP67 Cable gauge MAX 6.0 mm2 (10AWG) Diameter range 6 - 16 mm Operating temperature -40 C ~ +105 C Connecting mode Push locking Shell / insulating parts High-performance engineering plastics Contact material Copper alloy Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS Up to 50A on 2-4 pin version 2 to 16 pin configurations Push-locking, fast mating IP67 sealed UL94-V0 flame rating Power distribution Industrial machinery Outdoor lighting and signage Mixed power + signal cabling WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA M28 SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon M28 Series BAYONET ASSEMBLY TYPE / MOLDED CABLE TYPE / PANEL MOUNT TYPE M28 bayonet assembly type - specifications below TECHNICAL SPECIFICATIONS Number of contacts 2 Pin 3 Pin 4 Pin 5 Pin Current / Voltage rating 80A 600V 80A 600V 50A 600V 40A 300V Contact diameter 4.8 4.8 3.6 3.0 Withstanding voltage 2500V 2500V 2000V 1500V Protection level IP67 Cable gauge 6.0-16 mm2 (10-5AWG) 6.0-16 mm2 1.0-6 mm2 (18-9AWG) 0.8-5 mm2 (18-10AWG) Diameter range MAX 19.5 mm Operating temperature -40 C ~ +105 C Connecting mode Bayonet locking Shell / insulating parts High-performance engineering plastics Contact material Copper alloy Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS 80A rating on 2-3 pin Bayonet locking, vibration resistant Panel mount and molded cable versions IP67 sealed UL94-V0 flame rating Power supply and distribution boxes Industrial equipment Battery and inverter connections Outdoor enclosures WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA M40 SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon M40 Series BAYONET ASSEMBLY TYPE / MOLDED CABLE TYPE / PANEL MOUNT TYPE M40 bayonet locking type - specifications below TECHNICAL SPECIFICATIONS Number of contacts 4 Pin 5 Pin 2+4 Pin Current / Voltage rating 80A 600V 50A / 80A 600V 120A+10A 600V+60V Contact diameter 4.8 4.8 / 3.6 6.0 + 1.5 Withstanding voltage 2000V 2000V 2000V Protection level IP67 Cable gauge 2.0-16 mm2 (14-6AWG) 2.0-16 mm2 (14-6AWG) 5-25 mm2 (10-3AWG) / 0.5-1 mm2 (20-17AWG) Diameter range 16.0 - 25.0 mm Operating temperature -40 C ~ +105 C Connecting mode Bayonet locking Shell / insulating parts High-performance engineering plastics Contact material Copper alloy Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS Up to 120A on hybrid 2+4 pin Combined power + signal in one connector Large cable range up to 25 mm2 IP67 sealed UL94-V0 flame rating High-current power transmission Energy and substation equipment Industrial power cabinets Machinery with power + control lines WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA MJ SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon MJ Series MJ16 / MJ20 / MJ24 / MJ32 - PLASTIC AND METAL VERSIONS MJ32 quick-lock type - specifications below TECHNICAL SPECIFICATIONS Number of contacts 2 Pin 3 Pin 4 Pin 5 Pin Current / Voltage rating 120A / 600V 80A / 600V 80A / 600V 50A / 300V Contact diameter 6.0 4.8 4.8 3.6 Withstanding voltage 3000V 2000V 2000V 2000V Protection level IP67 Cable gauge 4-25 mm2 (10-3AWG) 4-16 mm2 (10-6AWG) 4-16 mm2 (10-6AWG) 1.0-6 mm2 (18-9AWG) Diameter range MAX 25.0 mm Operating temperature -40 C ~ +105 C Connecting mode Quick lock Shell / insulating parts High-performance engineering plastics Contact material Copper alloy Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS 120A on 2-pin version Quick lock with push-button release Available in plastic and metal shell MJ16 / MJ20 / MJ24 / MJ32 sizes IP67 sealed, UL94-V0 EV charging stations and wallbox Power supply units Energy storage systems Industrial power equipment WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA SINGLE-PIN ENERGY STORAGE CONNECTOR Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon Single-Pin Energy Storage Connector HIGH AMPERAGE SERIES - SNAP-TYPE - BLACK / ORANGE Single-pin energy storage connector - specifications below TECHNICAL SPECIFICATIONS Number of contacts 1 Pin Current rating 120A (25 mm2) / 150A (35 mm2) / 200A (50 mm2) Voltage rating DC 1000V / AC 800V Contact diameter 8.0 Withstanding voltage 3000V DC Protection level IP67 Cable gauge 25 mm2 / 35 mm2 / 50 mm2 Operating temperature -40 C ~ +125 C Connecting mode Snap-type Shell / insulating parts High-performance engineering materials Contact material Red copper plated with silver Flame-resistant rating UL94-V0 KEY FEATURES TYPICAL APPLICATIONS Up to 200A single-pin DC 1000V rated Snap-type fast connection Straight and 90 right-angle versions Black and orange coding Extended temp range to +125 C Battery energy storage systems (BESS) Battery packs and modules Inverters and power conversion EV and high-voltage DC systems WELCOME OEM / ODM

INDUSTRIAL CONNECTORS | DISTRIBUTED BY ELDECO ELETTRONICA WIRE HARNESS SERIES Eldeco Elettronica S.r.l. | Via Giordano Bruno 83, 10134 Torino, Italia | T +39 011 3804068 | info@eldeco.it euro-conn.com Manufactured by Jnicon Wire Harness Series CUSTOM CABLE ASSEMBLIES - WELCOME OEM / ODM Wire harnesses and cable assemblies built to customer drawing and specification. CAPABILITIES Custom wire harnesses to drawing Twisted, shielded and ribbon cable assemblies Ring, fork and blade terminals Connectorised leads and overmoulded cables T cable / Y cable / F cable configurations OEM / ODM development support Industrial waterproof connectors Eldeco Elettronica S.r.l. Via Giordano Bruno, 83 10134 Torino - Italia P.IVA 12062310011 T F E +39 011 3804068 +39 011 3806084 info@eldeco.it euro-conn.com Manufactured by Jnicon
