D-SUB STANDARD
Material
- Insulator: Glass-Filled Thermoplastic PBT, UL94V-0
- Contact: Brass
- Shell: Steel, 100u” Tin Over 50u” min Copper
- Clinch Nut: Brass, Nickel Plated
- Boardlock: Brass, Tin Plated
- Screwlock: Brass, Nickel Plated
Electrical
- Contact Resistance: 20 milliohms
- Insulation Resistance: 1000 megohms min. at 500 VDC
- Dielectric Withstanding Voltage: 1000 VAC/rms 60Hz for 1 minute
- Current Rating: 3 AMP
- Voltage Rating: 250 VAC/rms 60Hz
