PITCH mm 0,80
Material
- Contact Material: Brass
- Contact Plating: Au Over Ni
- Insulator Material: Polyester (UL94V-0)
- Standard: PA6T
- Max processing temp: 230°C for 30-60 seconds 260°C for 10 seconds
Electrical
- Rated Current: 0.75 AMP
- Contact Resistance: 30mΩ Max
- Withstand Voltage: 500V AC/DC
- lnsulation Resistance: 1.000MΩ Min
- Operation temperature: - 40°C to + 105°C
